Roof fan 24 volt round | Electric roof ventilation
This round electric roof fan from G&C ensures a healthy supply and exhaust of air in your commercial vehicle, camper or car. The roof fan is made of ABS and has a different shape than the LeMans. The voltage is 24 Volts and the consumption is 80 Watts. The fan is available in black and white.
You can reduce the fan noise by using a speed controller. The noise level is 52 DB and the speed is 2600 RPM. The airflow is 850 M³/H.
By using the 3-position switch you can let this fan in and out.
This switch is available separately or in the connection set.
To achieve optimum airflow, we advise you to install a floor vent.
This roof fan is standard supplied with a custom inner grille made of PVC in the color grey, insect filter / snow filter, sealing ring for a flat roof and an installation manual and drilling and sawing template.
With this set you will receive polymer sealant and mounting material for a roof thickness of 1-3 mm. The holes in the grille fit exactly on the ring of the roof fan. As a result, you need to drill fewer holes in the roof and installation is a lot faster.
We are the only ones on the market that offer this!
Application examples: Damp loading areas, animal transport, chemical transport, trucks, trailers, houseboats, mobile workshop, industrial machines.
Specifications:
* material: high quality ABS
* Extraction and supply of air
* Opening in roof: 224 mm
* Construction height: 62 mm
* air displacement: 850 M³ per hour
* Available in black and white
